Colloidal Mill is the machine mainly using for wet mixing, dispensing, emulsification, homogenizing and piratical size reducing application. Colloidal Mill is mainly use in food, beverages, chemicals, cosmetic, pharmaceuticals, pint, oil and gas, bitumen, asphalt etc. industries.
Colloidal Mill is work on the rotor and stator principal, Rotor and Stator is designed coaxially stages, which have radial slotted and a unique designed tooth was created. Design of rotor and stator, number of stages, number of tooth and material of Rotor and Stator are depending on the application data lick media viscosity, specific gravity, hardness, temperature, composition etc. Colloidal mill mainly designed as stator is fixed and rotor is rotating at hi speed (RPM), speed is also depending on the application. The media is entered in the system from the center of stator, because of high speed a centrifugal force is created and media is flow the outside from stages of rotor and stator where minimum gap between rotor and stator is ensure the proper mixing and homogenizes of liquid or solid.
AMT TECHNO is developed a unique combination of rotor and stator for Bitumen Emulsion and PMB/CRMB which give the proper particle size distribution and better result in the final product. AMT TECHNO also serves the Colloidal Mill and Homogenizers to application like pharmaceutical, food, beverages, chocolate, cosmetics, paint etc. Our Research and Development department is also work for each and individual requirement and can do small testing and take small batches of your product on our small laboratory Colloidal Mill at AMT TECHNO headquarter before purchasing the machine.
| Standard Models of AMT Colloidal Mill | |||||
|---|---|---|---|---|---|
| Model And Technical Details | AMT-LAB | AMT-05 | AMT-09 | AMT-36 | AMT-54 |
| Mixing, Emulsification, Dispensation, Homogenization Capacity: M³/Hour | 0.5 To 2 | 3 To 20 | 7 To 40 | 20 To 100 | 50 To 200 |
| Connection Size | 25MM (1”) | 40MM (1 ½”) | 50MM (2”) | 100MM (4”) | 150MM (6”) |
| Rotating Speed | 2900 To 5600 RPM | 1500 To 2900 RPM | 1500 To 2900 RPM | 1500 To 2900 RPM | 1500 To 2200 RPM |
| Motor Capacity (HP) | 1-3 | 10-40 | 15-150 | 60-150 | 90-200 |
